DM(X)

Today I discovered a very nice Analysis Services client tool. Produced by SQLMinds, the tool seems a great addition to Analysis Services. It provides many components, among them a performance tuning service, an OLAP cube browser for the web and a very nice web front end for data mining, the DM Companion tool which can be launched at http://x32.sqlminds.com/dmcompanion.

So, here are a few really nice things about the DM Companion tool (BTW, a fully working demo is running at the aforementioned URL).

The tool works to some extent like a Data Mining -specific SQL Server Management Studio for the web. Therefore, it allows you connect to the server of your choice (through the Analysis Services HTTP pump). The demo seems to allow anonymous connections (pretty safe  as all the interactions offered by the tool are read-only).  Next you get to chose your AS catalog and the mining model you want to use.

For each model you have the option to browse the content or execute predictions.

The prediction feature provides a nice interface for defining singleton predictions, as you can see below:

The interface supports specifying multiple nested table keys as input, so the tool can perform associative predictions as well. It reminds me of the XMLA Thin Miner sample running on SQLServerDatamining,com, however, it looks much better and is nicely integrated with the rest of the application. While prediction functions do not seem to be directly supported, the application is able to predict a cluster for clustering models.

The model browsing features are really nice. Analysis Services includes a set of sample web viewers for Naive Bayes, Trees and Clustering. This application provides some seriously better looking viewers for these algorithms, and extends the suite at least for Neural Networks (a really nice viewer), Sequence Clustering and Association Rules.  The DM Companion viewers offer all the features in the sample viewers, with a nicer implementation which uses AJAX and has better graphics, plus a solid set of new features, the most spectacular being the interactive dependency net browser and the pie chart visualization for decision trees, which you can see below.

Overall, DM Companion looks like a really nice tool for sharing your data mining implementation on the web

Tags: DMX // 1 Comment »

Some very interesting, although time-consuming project kept me away from posting in the last month. Mea maxima culpa, I will try to catch up and put some new and interesting content here more often.

Recently, trying to make sense of some prediction results, I realized that the DMX NATURAL PREDICTION JOIN statement has some obvious and some not so obvious dangers, which deserve some clarification.

To summarize, the PREDICTION JOIN operator is used to apply patterns from a trained mining model against new data. The general syntax is

SELECT EducationLevel

FROM MyModel

PREDICTION JOIN

OPENQUERY(MyDataSource, ”SELECT Height, , HairColor, ShoeSize FROM CustomerInfo’) AS T

ON

T.Height = MyModel.Height AND

T.HairColor = MyModel.HairColor AND

T.ShoeSize= MyModel.ShoeSize

In the standard PREDICTION JOIN statement, the ON clauses specify how columns from the new data are to mapped to the input columns of the mining model.

The statement supports a simplified format:

SELECT EducationLevel

FROM MyModel

NATURAL PREDICTION JOIN

OPENQUERY(MyDataSource, ”SELECT Height, HairColor, ShoeSize FROM CustomerInfo’) AS T

In the simplified format, the columns from the new data are mapped to the input columns of the mining model by name. Much easier to type, resulting in a more readable statement!

Now, the natural mapping may end up in three different scenarios. In the first scenario, all the model’s input columns find a corresponding data column in the input. The mapping is performed correctly and everything works as expected. Nothing to blog about in this case!

The second case: some of the inputs are mapped correctly to model columns, some are not, although you would expect them to be mapped correctly. More than a simple user error, this situation is actually “facilitated” by the way the BI Dev Studio works. Assume you start with a table containing 4 columns: Height, HairColor, ShoeSize, EducationLevel and use BI Dev Studio to create a mining structure and a model. BI Dev Studio will generate more friendly names for the columns and your mining model ends up with the structure below:

MyModel

(

Height

[Hair Color],

[Shoe Size],

[Education Level]

)

[Read more →]

Tags: DMX // 1 Comment »

MyVBProf.com hosts a set of great video tutorials for performing business intelligence tasks with Excel 2007. Bill Burrows starts with the installation of pre-requisites. He even shows how to make sure that Excel .Net Programmability Support is available! Wow!!

Bill then follows up with a set of tutorials on pivot tables and wraps up with videos on using the Table Analysis Tools from the SQL Server Data Mining add-ins for Excel. His approach is accessible, his style is captivating, his examples are meaningful and very well explained.

Therefore:

1. If you have SQL Server 2005 or 2008 CTP these tutorials give you a great start for BI using Excel and Analysis Service.

2. If you do not have SQL Server, get a free evaluation from http://www.microsoft.com/sql/downloads/trial-software.mspx, then go back to the previous point

3. You don’t have SQL Server, don’t want to try it out, don’t care about the data mining part — fine, just watch some of the tutorials to see what you miss!

Tags: Excel Add-ins // 5 Comments »

A recent post on the MSDN Forums raises the issue of reconstructing the Microsoft Neural Network and reproducing the prediction behavior based on the model content. The forum did not allow a very detailed reply and, as I believe this is an interesting topic, I will give it another try in this post. As an example, I use a small neural network which is trained on two inputs, X (having the states A and B) and Y (C and D) in order to predict a Z discrete variable, having the states E and F.

This post is a bit large, so here is what you will find:

• - a description of the topology of the Microsoft Neural Network, particularized for my example
• - a step-by-step description of the prediction phases
• - a set of DMX statements that exemplify how to extract network properties from a Microsoft Neural Network mining model content
• - a spreadsheet containing the sample data I used as well as a sheet which contains the model content and uses cell formulae to reproduce the calculations that lead to predictions (the sheet can be used to execute predictions for this network)

The network topology

Once trained, a Microsoft Neural Network model  looks more or less like below:

During prediction, the input nodes are populated with values deriving from the input data. The values are linearly combined with the edges leading from input nodes to the middle (hidden) layer of nodes and the input vector is translated to a new vector, which has the same dimension as the hidden layer. The translated vector is then “activated” using the tanh function for each component. The resulting vector goes through a similar transformation, this time from the hidden layer to the output layer. Therefore, it is linearly converted to the output layer dimensionality (using the weight of the edges linking hidden nodes to output nodes). The result of this transformation is activated using the sigmoid function and the final result is the set of output probabilities. These probabilities are normalized before being returned as a result (in a call like PredictHistogram)

[Read more →]

Tags: Modeling // 4 Comments »

This an actual question I had to answer in one of the previous Tech Ready conferences: when does one know that feeding more data to the mining model will stop improving accuracy? Or: how much training data is enough? With the new accuracy procedures in SQL Server 2008, I think I have now a better answer.

Algorithms learn from data and, generally, feeding them with more data will improve the accuracy. This improvement, however, is asymptotical. If the training data is statistically representative for the problem space, then a classifier will stop learning after a certain limit: new data points will support existing patterns and will help reducing the risk of over-training,  but will not add more information to the model. The solution I suggest for SQL Server 2008 allows you to figure out if your mining model is likely too gain from adding new data or is likely to maintain the same accuracy.

The solution is based on the cross validation mechanism, so I’ll start with a small presentation of this mechanism. The cross-validation takes a data set, splits it into a number of (roughly equal size) partitions, called folds, then builds a set of mining models (as many as there are folds). Each mining model is built on top of the whole data set minus one of the folds and then the accuracy of the model is measured on the fold that was left out. Effectively, all data is used in training and all data is left out (by at least one mining model). Also, each model is validated against data that was not seen during training. The accuracy measures for each model are then evaluated across all the folds. A good mining solution would provide compact accuracy measurements (i.e. no big differences between the measurements on different folds). Spikes in the measurements may indicate problems with the data. Note that cross validation does not improve the accuracy of the model, it just provides an “honest” estimation of that, reducing the risk of over-training.

In SQL Server 2008, cross validation allows the user to specify how many cases should be used for the procedure. This is mainly for performance purposes — it allows a quick comparison between different mining models/algorithms on the same data set.

Now back to the original problem: would adding new data benefit the accuracy?

[Read more →]

Tags: 2008, DMX, SQL Server // Add Comment »

This second post on model filtering deals with nested table filters. The most common use of nested tables in SQL Server Data Mining is to model transaction tables. That is, model Customer entities together with the “bag” of products they purchased.

Nested table filters primarily serve two purposes:

• - Use (in the model) only those nested table rows with a certain property (e.g. consider only products that are not “Coca Cola”, because most people do buy “Coca Cola”, so it is not that interesting)
• - Use (in the model) only those cases where the associated nested tables have certain properties (e.g. - build a prediction model on customers that have purchased Coca Cola)

Notice the difference between the filters: while the first filter removes products from shopping baskets before modeling, the second removes customers from the model (those that have not purchased Coca Cola).

[Read more →]

Tags: 2008, DMX, Modeling, SQL Server // Add Comment »

This is the first post in a small series describing my favorite data mining feature in SQL Server 2008, model filtering. Filtering allows you to take full advantage of the mining structure / mining model dichotomy, separating the data staging (in the structure) from the modeling (in the mining model).

SQL Server 2008 allows specifying, for each mining model, a filter to be applied on the training data. The filter acts as a partitioning mechanism inside the mining structure and it is applied on top of any training/testing partitioning already existing at the structure level.  Furthermore, filters can be applied to data in nested tables, but more about this in the next post. Filters allow you to build different models for various partitions of the data with minimal effort, either to obtain better overall accuracy (think of it as manually specifying the first split in a decision tree), or to compare the patterns between different partitions.

So, let’s start with a simple scenario, using the same old Adventure Works data - building a mining model that predicts how likely a customer is to purchase a bike based on various demographic information. Let’s also assume that you know, based on your experience with the data that the Geography factor has in important role and you don’t want your North American patterns to hide (because of volume) the peculiarities of the Pacific market.

Suppose you start with a mining structure defined like below:

[Read more →]

Tags: 2008, DMX, SQL Server // Add Comment »

In a previous post I presented some of the new DMX features in the November CTP of SQL Server 2008. So, here are some new cool DMX tricks.

Assume you want to use Microsoft Association Rules and Microsoft Decision Trees on the same data. Also, assume that the data contains one numeric column (say, Age). You may have noticed that Decision Trees supports continuous columns, while Association Rules does not. Not a big deal, we have discretization, and Age can be added twice to the same mining structure as, say Age (Continuous) and Age Disc (Discretized). However, the two different names raise a problem in the case of NATURAL PREDICTION JOIN (where input columns are bound by name to the model columns).

In SQL Server 2005, the mining model columns typically had the same name as the mining structure’s ones. There was no way in DMX to change the model column names (well, there is a way in BI DevStudio).

Another problem: one would not include the email, name or phone number of a customer in a mining model, because, at best, this would increase training time and, in the worst case, would unnecessarily complicate the model with fake patterns. But this makes it hard to link the training cases leading to one pattern (available with the drillthrough feature) to information that would perhaps make that pattern actionable (like contact information, if the pattern suggest strong probability to buy a product).

In 2008, these problems are much easier to solve, with mode column aliasing and structure columns drillthrough, and here is how these work.

[Read more →]

Tags: 2008, DMX, SQL Server // Add Comment »

You may have noticed, our community site has changed. Besides better graphics (including a new and improved question mark for the forums link), it looks better and, more important, it should run much better. The hardware received a much needed upgrade and the community platform was changed from the old ASP.Net Community Starter Kitt to the newer, more scalable, DotNetNuke.

More important — the site now runs SQL Server 2008 (the November CTP). You should notice a difference in the performance of the Live Samples .

The new framework uses a new link system. We tried to make sure that all the old links still work (directly or via a redirector). However, if you find a broken link on the new site, please let us know by sending a mail to the DM Team .

Tags: 2008, SQL Server, Uncategorized // 1 Comment »

As Raman mentioned in the Data Miner newsletter, the November CTP of SQL Server 2008 is now available.

It includes many really cool new features in Analysis Services. Among them: Holdout support, Model filtering, DMX Column aliasing, Drillthrough enhancements, Cross validation and practically two new forecasting algorithms under the Microsoft_Time_Series umbrella.
I intend to present all of them briefly, and I start today with the Holdout support.

Most of the data mining tasks require a validation step, performed right after modeling. This validation step
consist (typically) in evaluating model’s performance against data that was not seen during training (test data).

The test data ideally has the same statistical properties as the training data (data seen by the mining model during training). An easy way to achieve statistical similarity between the training and test set is to use random sampling. This method is not guaranteed to give correct results (statistical similar populations) but, assuming that the random sampling mechanism is independent of the data, it will work in most common scenarios.

SQL Server Integration Services has a Random Sample transform, which extracts a random sample (with a certain percentage) using a mechanism independent of the actual data being samples. This is why we strongly recommended using Integration Services to generate test/training partitions for SQL Server Data Mining.

However, there are a few problems:
- Integration Services will have to save at least one of the sample sets in a relational table (or some form of output destination)
- This sampling method can only be applied to data coming from a relational source (or, in general, a source that can be used with IS). That means it is difficult to use IS sampling with application that do data mining on in-memory data
- Integration Services is rather hard to use to sample data for models with nested tables. It can be done, but it takes around 11 simple steps and 14 transforms to do this for a single nested table (an example is available here: Sampling Nested Tables )

Now, there is a simpler way to do this. You may remember that, in the SQL Server Data mining architecture, a Mining Structure object acts as a data space while a mining model is a problem to be addressed in that data space. As the mining structure describes the data space, it is  natural for the structure to partition the data into training and testing sets.

In SQL Server 2008, the new wizard for creating a model (or structure — yes, there is a wizard now for creating a structure with no models!) allows specifying the desired size of the “Holdout” dataset — that is, data to be stored in the mining structure for testing purposes, without being available for models training. By default, the holdout size is 30% (leaving 70% for training). You may choose to specify a fixed number of rows instead of a percentage, or both (in this case the semantic is “use 30%, but no more than 10000 rows for test data”).

The rest of this post shows how to express the holdout wizardry in DMX.

[Read more →]

Tags: 2008, DMX, SQL Server // Add Comment »
